Safer Schools:
Making
the Grade

Explore this knowledge base for tools and resources to design or build safer schools.

Since 2000, schools have been the

2nd most frequent

targets in active shooter incidents.
-FBI, Via Partner Alliance For Safer Schools

There are about

3,230 fires

in educational buildings each year.
- The International Association of Fire Chiefs

Because safer school design includes security and fire and life safety, it is important to consider areas that need one form of protection or the other as well as applications where multiple concerns overlap.

Are Forced Entry Requirements Included in Current Building Codes? Sadly, No.

See How Building Codes Have Impacted School Design Over the Last 50 Years

Creating safe learning environments in schools is a timely concern. The following timeline highlights the major changes to fire-rated glazing requirements in the International Building Code (IBC). In 2023, states like Texas, Tennessee and Missouri passed laws that require schools to harden exterior openings, representing a greater emphasis on safer school design nationwide. With this in mind, we look forward to a future where security-rated glazing is driven by model code requirements.

1970s

Traditional wired glass granted exemption in high-impact areas.

2003

Exemption narrowed for traditional wired glass for hazardous locations in schools, athletic facilities and daycares.

2006

Exemption revoked for traditional wired glass in ALL types of buildings.

2012

Simplified labeling for fire-rated glazing.

Elimination of sprinkler trade-offs in key markets.

Clarified requirements for where fire-protective & fire-resistive products can be used.

2027

Security glazing requirements in schools?

The Basics: Fire-Rated, Fire + Security-Rated Glass and Framing

You have questions. We have answers to a variety of common fire-rated and fire + security-rated topics. Explore these important issues relevant to your school design, and if you aren’t finding what you’re looking for, always feel free to contact us.

Fire

Q. What is fire-rated glass?

A. Like most glass, fire-rated glazing allows light and visibility for aesthetic or security reasons. But fire-rated glass does something more: It acts as a barrier to the spread of flames and smoke, containing it within a limited space. In the world of fire protection, this is known as “compartmentation.”

Unlike sprinklers or other “active” protection systems, fire-rated glass does not require activation in order to protect against fire. If there is a power failure, a loss of water pressure, or a human error that interferes with the sprinklers working properly, fire-rated glass will not be affected and will continue to perform as needed.

Q. What is the difference between fire-protective and fire-resistive glazing?

A. Explore the two types of glazing systems to understand: “fire-protective” and “fire-resistive.” While they sound similar, there are some distinct differences between the two.

Fire-Protective

Fire-protective glazing can be counted on to defend against the spread of flames and smoke for a designated amount of time, which is indicated by a fire rating. This type of glazing is available with fire ratings from 20 to 90 minutes depending on the glass.

Fire-Resistive

In addition to blocking flames and smoke, fire-resistive glazing products limit the transfer of heat through the glass. This adds another layer of safety and makes the glass suitable for use in doors, walls and other fire-rated assemblies that are required to block the passage of excessive heat, hot gases and/or flames.

This type of glazing can typically be used where building codes require an assembly designated “fire resistant” to enclose a space.

Fire-resistive glazing is tested to the same standards as solid barrier walls, and therefore is not limited to 25 percent of the wall as is fire-protective glass. This type of glazing is versatile in design since it eliminates the need for opaque materials such as masonry or gypsum in areas that require fire-rated walls and allows for virtually unlimited expanses of glass.

Q. When is impact-safety-rated glass required for fire-rated applications?

A. A school’s fire-rated areas are subject to the same impact safety standards as non-rated areas. The chances of fire may be slim, but the danger of breakage looms daily. A door at the end of a school hallway may have to endure regular contact with students who push, press and slam their way through.

Glass in hazardous locations must meet impact testing requirements, as well as fire testing. As with fire ratings, impact safety ratings offer different levels of resistance, depending on the need. The highest rated products are strong enough to withstand the force of a full-grown adult running into them.

Fire + Forced Entry

Q. What is the difference between safety glazing and security glazing?

A. Safety and security may sound synonymous, but when it comes to glazing, they are technical terms that refer to separate categories of glass.

Safety Glazing

One of the most common forms of safety glazing is impact-safety-rated glass. As mentioned earlier, impact safety ratings measure a product’s ability to offer protection against accidental human impact. This not only indicates that it will resist breakage—it also means that if broken, the glass will do so in a manner that will not leave dangerous shards. This is why at the scene of an auto accident you will find small beads of glass rather than large, sharp-edged pieces. The glass must break in such a way that it will not become a source of further injury.

Besides human impact, some forms of safety glazing also account for natural causes of breakage as well. These can include hurricanes, tornadoes, earthquakes and wind load.

Security Glazing

Like safety glass, security glass also offers protection. Specifically, security glazing is that which protects from forced entry, ballistics, and blast. This type of glass can also be bullet resistant and blast resistant.

For example, in the event of an intruder attack, forced entry glass gives students and staff the upper hand by taking away the element of surprise at access points and delaying ingress.

Security glazing is also available with fire ratings. It helps ensure the product meets all performance criteria, and isn't prioritizing security over safety, and vice versa.

Q. Is security glazing code driven? Are there security tests for glass that pertain to schools?

A. While building codes require the use of fire-rated glazing in specific applications, they do not currently mandate the use of security glazing in educational facilities. However, the industry is working to tighten regulations. In 2018, at least 53 new school safety laws were passed in states, and districts are spending millions of dollars to “harden” schools with improved security measures.

Q. What are the important security-rated standards that pertain to schools?

A. More than 40 different voluntary tests apply to security issues, from forced-entry to ballistics to blast-resistance. However, building codes do not currently mandate security glazing in educational facilities.

With the groundswell of interest in making schools safer, task groups such as American Society for Testing and Materials, International (ASTM) are working diligently to reach consensus on a security test standard. And other parties (like the National Glass Association) are looking at ways to provide manufacturing guidelines for school security glazing in the interim.

Some school districts are not waiting for industry-wide standardization, but are adopting the voluntary security standards to enhance the protection of their students. Of all the existing tests, ASTM E2395 is most applicable to slowing down unskilled or semi-skilled intruders. This test of window and door systems projects pieces of 2” x 4” lumber from an air cannon at the glass. The same glass is then struck multiple times with a ball-peen hammer.

When it comes to bullet-resistant security glazing, UL 752 is the test standard most commonly referenced. Rounds of different types of ammunition are fired at the glass from a distance of 15 feet. A piece of corrugated cardboard is placed 18 inches behind the glass as a “witness plate.” A successful test will not only mean the glass stopped the ammunition, but also no spalling from the glass reached the cardboard. Ratings are assigned in levels from 1 to 8, able to stop a 7.62 mm rifle lead core full metal copper jacket, military ball from a submachine gun or assault rifle.

Partners And Associations

TGP is committed to leading the charge for safer schools by partnering with associations and voices dedicated to this important issue. Together we will improve school safety through design.

Beyond the Basics: Fire-Rated, Fire + Security-Rated Glass and Framing

How does fire-rated glazing fit into school design? from renovation to new builds, fire-rated glazing has an important role.

Get the Story

What type of fire-rated glass is used In today's schools?

Today, architects and designers have a broad range of options at hand.

Read More

What's the difference between forced-entry, bullet resistant-rated glass and ballistic glass?

With no universal standard to rely on, learn more about the various options to enhance school security.

See the Article

Products
And Solutions

Discover a variety of fire and fire + forced entry glazing options to mitigate risks and push design options forward. Critical functions can be combined in customized ways and specified in a single product that performs on multiple levels. Innovative school design does not have to compromise aesthetics for safety and security.

Glass & Fire Solutions

Glass | Fire

Glass & Fire + Security Solutions

Glass | Fire + Security

Frames & Fire Solutions

Frames | Fire

Frames & Fire + Security Solutions

Systems | Fire + Security

School Design Resources

Articles

Articles

Stay updated on the evolving conversation around designing safer schools.

See Our Latest Articles

Case Studies

Case Studies

Be inspired and gain best practices from past projects for safe-school design.

Explore All Case Studies

Expert Insights

Expert Insights

Learn more about school safety from the pros in the field.

Explore

Talk to an Expert

Contact us to speak to a skilled school design pro.
